The Citizen CMP-20 mobile printer is designed to be simple and easy to use, just like other Citizen printers. Its durable, robust plastic casing provides excellent impact resistance, ensuring the CMP-20 mobile printer remains operational.

The CMP-20 features a high-capacity media magazine that can hold roll media with a diameter of approximately two inches, ensuring long printing sessions without the need for media reloading.

Furthermore, the CMP-20 is equipped with a high-capacity battery, providing users with a full day of printing capability.

With its compact design, robust construction, and powerful functionality, the CMP-20 printer is an ideal choice for mobile printing solutions.

Citizen CMP-20 Features:
◆ Easy media loading with paperless indicator.
◆ Tear-off lever.
◆ Lithium-ion battery and easy-to-recharge power module.
◆ Direct charging design with AC adapter.
◆ Multi-interface design, including USB, RS232, Bluetooth, and WLAN network interfaces.
◆ Optional magnetic stripe reader and IC card reader.
◆ Windows drivers and software development kit.

Citizen CMP-20 Applications:
◆ Mobile Receipts
◆ Queue Systems
◆ Delivery Notes
◆ Price Reduction Lists
◆ Labels
◆ Ticketing
◆ Payment
◆ Taxi Receipts

Citizen CMP-20 Detailed Specifications:
Printing Method: Direct Heating
Printing Speed: Maximum 80mm/sec
Printer Class: 2-inch
Print Width: 48mm
Media Width: 58mm
Media Roll Size: Up to 48mm in diameter
Characters per Line: 32 characters (Font A); 42 characters (Font B)
Resolution: 203dpi
Dots per Line: 384 dots/line
Interface Version: RS232C Serial Port: Standard interface, 115000bps, 7 or 8-bit, 8-pin mini DIN connector; USB: Standard interface, USB 2.0, mini interface, Type B; Bluetooth: Factory optional, Class 2, V2.0, 2.4GHz FH, 10 meters, 115Kbps, SPP Profile; Wireless LAN: Factory optional, 802.11b and 802.11g, 100 meters, 64/128-bit WEP, WPA, 54Mbps;
Magnetic Strip Reader: Factory optional, ISO 7811/2, JIS standards. Dual track (1+2, 2+3), 10-15 cm/s reading speed.
IC card reader: Factory optional, 9600bps reading speed, 1 internal channel.
Casing design: High-strength ABS plastic.
Dimensions: 96mm*136mm*58mm.
Weight (including battery): Approximately 0.44Kg.
Battery type and capacity: Lithium battery, 7.4V, 1900mAh.
Charger: Input: 100V-240VAC, 50/60Hz; Output: 8.4V, 1200mA.
Protection rating: IP42.
Drop test: Multiple drops from 1.5 meters.
Emulation language: ESC/POS.
Drivers: Windows compatible drivers for desktop and mobile operating systems.

The Citizen CMP-30 mobile printer is designed to be simple and easy to use, just like other Citizen printers. Its durable, robust plastic casing provides excellent impact resistance, ensuring the CMP-30 mobile printer remains operational.

The CMP-30 features a high-capacity media magazine that can hold roll media with a diameter of approximately two inches, ensuring long printing sessions without the need for media reloading.

Furthermore, the CMP-30 is equipped with a high-capacity battery, providing users with a full day of printing capability.

With its compact design, robust construction, and powerful functionality, the CMP-30 printer is an ideal choice for mobile printing solutions.

Citizen CMP-30 Features:
◆ Easy media loading with paperless indicator.
◆ Tear-off lever.
◆ Lithium-ion battery and easy-to-recharge power module.
◆ Direct charging design with AC adapter.
◆ Multi-interface design, including USB, RS232, Bluetooth, and WLAN network interfaces.
◆ Optional magnetic stripe reader and IC card reader.
◆ Windows drivers and software development kit.

Citizen CMP-30 Applications:
◆ Mobile Receipts
◆ Queue Systems
◆ Delivery Notes
◆ Price Reduction Lists
◆ Labels
◆ Ticketing
◆ Payment
◆ Taxi Receipts

Citizen CMP-30 Detailed Specifications:
Printing Method: Direct Heating
Printing Speed: Maximum 100mm/sec
Printer Class: 3-inch
Print Width: 72mm
Media Width: 25-80mm
Media Roll Size: Diameter up to 56mm
Characters per Line: 48 characters (Font A); 64 characters (Font B)
Resolution: 203dpi
Dots per Line: 576 dots/line
Interface Version: RS232C Serial Port: Standard interface, 115000bps, 7 or 8-bit, 8-pin mini DIN connector; USB: Standard interface, USB 2.0, mini interface, type B; Bluetooth: Factory optional, Class 2, V2.0, 2.4GHz FH, 10 meters, 115Kbps, SPP Profile; Wireless LAN: Factory optional, 802.11b and 802.11g, 100 meters, 64/128-bit WEP, WPA, 54Mbps;
Magnetic Strip Reader: Factory optional, ISO 7811/2, JIS standards. Dual track (1+2, 2+3), 10-15 cm/s reading speed.
IC card reader: Factory optional, 9600bps reading speed, 1 internal channel.
Casing design: High-strength ABS plastic.
Dimensions: 120mm*70mm*152mm.
Weight (including battery): Approximately 0.63Kg.
Battery type and capacity: Lithium battery, 7.4V, 2200mAh.
Charger: Input: 100V-240VAC, 50/60Hz; Output: 8.4V, 1200mA.
Protection rating: IP42.
Drop test: Multiple drops from 1.5 meters.
Emulation language: ESC/POS+CPCL.
Drivers: Windows compatible drivers for desktop and mobile operating systems.

The Citizen CLP8301 is a 300DPI industrial-grade A4 wide-format barcode printer, offering high print clarity and speed.

It’s suitable for high-speed thermal printing of thermal documents like invoices and labels, as well as thermal transfer printing on various special materials.

The product boasts stable quality, excellent performance, ease of operation, a compact design, small footprint, and reliable operation, earning widespread praise from users.

Its large A4 width, high-capacity paper tray, and high-capacity ribbon roll make it suitable for high-volume and industrial-intensity printing requirements.

It is primarily used by large logistics companies, public institutions, financial institutions, and transportation management departments.

Citizen CLP8301 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 450-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, simpler and faster.
◆ Long-life printhead (30% more durable than comparable products)
. ◆ Adjustable label sensor allows for quick setting of special labels.
◆ Equipped with 8 MB of DRAM and 2 MB of flash memory, easily and quickly handling large print data tasks.
◆ Utilizes a powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with three standard printing interfaces (IEEE 1284 high-speed parallel port and serial port), and optional USB, network card, and WIFI interfaces.
◆ Built-in power supply eliminates the need for bulky external power supplies.
◆ Optional cutter module to enhance the flexibility of printing applications.

Citizen CLP8301 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 300 DPI (11.8 dots/mm)
Printing Speed: 1–4 inches/second (2.54–100 mm/s)
Print Width: 219.5 mm (8.6″)
​​Label Width: 76.2–228.8 mm
Motherboard Memory: 8MB SDRAM, 2MB Flash ROM
Processor: 32-bit RISC High-Speed ​​Processor
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM UPS
2D Barcode: MaxiCode, PDF417, Data Matrix, and QR code
English Fonts: 8 bitmap fonts, 1 Scalable font, supports TrueType font download
Chinese Fonts: None
Instruction Language: Datamax instruction set, Zebra ZPL II instruction set (optional)
Standard Ports: IEEE 1284 parallel port, RS-232 serial port (25 pins) Label
Specifications: Width 76.2-228.6mm, Thickness 0.063-0.254mm, Length 12.7-508mm (Roll or Fold)
Paper Container Specifications: Label paper roll, outer diameter 200mm (8″), inner diameter 76mm (3″)
Product Specifications: 395 x 415 x 260 mm
Product Weight: 18kg
Optional Accessories: Electric cutter, induction tear device (optional, customer must order at their own expense)

The Citizen CL-S6621 is a unique 6-inch wide-format thermal transfer barcode printer that can print labels between 4-inch and 8-inch widths.

With the smallest size among 6-inch printers, the CL-S6621 utilizes all the technology of the proven 4-inch CL-S621 printer and adds 6-inch printing capabilities, making it the best choice for your 6-inch wide-format printing needs.

Citizen CL-S6621 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 360-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, easier and faster.
◆ ARCP ribbon anti-wrinkle and automatic tensioning system.
◆ Long-life printhead (more than 30% more durable than comparable products).
◆ Adjustable label sensor allows for quick setting of special labels.
◆ Powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with two standard printing interfaces (serial and USB), and optional network card, Wi-Fi wireless card, and IEEE 1284 high-speed parallel port.
◆ Built-in power supply eliminates the need for a bulky external power supply.
◆ Optional paper peeler and cutter modules are available to enhance the flexibility of printing applications.

Citizen CL-S6621 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 203 DPI (8 dots/mm)
Printing Speed: 1–6 inches/second (2.54–150 mm/s)
Print Width: 168 mm
Media Width: 50 mm–178 mm
Media Thickness: 0.0635 mm–0.254 mm
Media Length: 6.4 mm–812.8 mm
Maximum Outer Diameter of Media Roll: 127 mm
Media Sensors: Fully Adjustable Label Gap/Notch Sensor, Black Mark Sensor, Media Low Sensor
Ribbon Size: 25.4 mm Core, Maximum Outer Diameter: 74 mm
Ribbon Winding Method: External or Internal Carbon
Ribbon System: ARCP Ribbon Anti-Wrinkle and Automatic Tensioning System
Standard Interfaces: RS-232C, USB 2.0
Optional Interfaces: Parallel Port, Ethernet, WIFI LAN (802.11bgn)
RAM: 32MB, 1.0MB available for users
Flash: 32MB, 1.0MB available for users
Control Panel: 8MB, 1.0MB available for users
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR code
English Fonts: 8 bitmap fonts, 1 Scalable font, supports TrueType font downloads
Chinese Fonts: None
Instruction Languages: Datamax instruction set, Zebra ZPL II instruction
set Standard ports: RS-232 serial port (25-pin), USB 1.10
Optional ports: IEEE 1284 parallel port, Ethernet interface
Product dimensions: 303 x 290 x 273 mm
Product weight: 7.9 kg
Optional accessories: Cutter, Tag peeler

The Citizen S703 is a heavy-duty industrial-grade barcode printer with a 306 DPI resolution.

It boasts high print clarity, fast printing speed, heavy-duty industrial strength, a 32-bit high-speed CPU, 20MB of large-capacity memory, and ARCP anti-wrinkle, anti-slip, and pre-positioning structures. It delivers excellent and stable print quality and a durable printhead.

Primarily used by customers in high-quality manufacturing, logistics, apparel, government agencies, banks, and highways, the product is highly user-friendly and has received widespread praise from users.

Citizen S703 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 450-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, simpler and faster.
◆ Long-life printhead (over 30% more durable than comparable products)
. ◆ Adjustable label sensor allows for quick setting of special labels.
◆ Equipped with 16 MB of DRAM and 4 MB of flash memory, easily and quickly handling large print jobs.
◆ Powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with three standard printing interfaces (IEEE 1284 high-speed parallel port, serial port, and USB interface), and optional network card and WIFI interface.
◆ Built-in power supply eliminates the need for a bulky external power supply.
◆ Optional paper peeler and cutter modules are available to enhance the flexibility of printing applications.

Citizen S703 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 306 DPI (12 dots/mm)
Printing Speed: 1–8 inches/second (2.54–200 mm/s)
Print Width: 104 mm
Maximum Paper Width: 118 mm
Motherboard Memory: 16MB SDRAM, 4MB Flash ROM
Processor: 32-bit RISC High-Speed ​​Processor
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR English font library
: 8 bitmap fonts, 1 Scalable font, supports TrueType font download
Chinese font library: None
Instruction language: Datamax instruction set, Zebra ZPL II instruction set (optional)
Standard ports: IEEE 1284 parallel port, RS-232 serial port (25 pins), USB 1.10
Tag specifications: Width 19.5-118mm, Thickness 0.063-0.254mm, Length 6.4-812mm Roll or folding
Paper specifications: Label paper roll, outer diameter 127mm (8″), inner diameter 25.4～76mm (1～3″)
Product specifications: 255 x 490 x 265 mm, (10″ x 19.3″ x 10.4″)
Product weight: 13.3kg
Optional accessories: Electric cutter, external rewinder (optional, customer must order at their own expense)

The Citizen S700 is a high-strength, high-speed, 203 DPI heavy-duty industrial-grade barcode printer.

It boasts powerful printing capabilities and industrial-grade durability, a 32-bit high-speed CPU, 20MB of large-capacity memory, and an ARCP anti-wrinkle, anti-slip, and pre-positioning structure.

It delivers excellent and stable print quality with a durable printhead. Primarily used by customers in manufacturing, logistics, apparel, government agencies, banks, and highways, its user-friendly operation has earned it widespread praise from users.

Citizen S700 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 450-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, simpler and faster.
◆ Long-life printhead (30% more durable than comparable products)
. ◆ Adjustable label sensor allows for quick setting of special labels.
◆ Equipped with 16 MB of DRAM and 4 MB of flash memory, easily and quickly handling large print data tasks.
◆ Utilizes a powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with three standard printing interfaces (IEEE 1284 high-speed parallel port, serial port, and USB interface), and optional network card and WIFI interface.
◆ Built-in power supply eliminates the need for bulky external power supplies.
◆ Optional paper peeler and cutter modules are available to enhance the flexibility of printing applications.

Citizen S700 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 203 DPI (8 dots/mm)
Printing Speed: 1–10 inches/second (2.54–254 mm/s)
Print Width: 104 mm
Maximum Paper Width: 118 mm
Motherboard Memory: 16MB SDRAM, 4MB Flash ROM
Processor: 32-bit RISC High-Speed ​​Processor
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR English font library
: 8 bitmap fonts, 1 Scalable font, supports TrueType font download
Chinese font library: None
Instruction language: Datamax instruction set, Zebra ZPL II instruction set (optional)
Standard ports: IEEE 1284 parallel port, RS-232 serial port (25 pins), USB 1.10
Tag specifications: Width 19.5-118mm, Thickness 0.063-0.254mm, Length 6.4-812mm Roll or folding
Paper specifications: Label paper roll, outer diameter 127mm (8″), inner diameter 25.4～76mm (1～3″)
Product specifications: 255 x 490 x 265 mm, (10″ x 19.3″ x 10.4″)
Product weight: 13.3kg
Optional accessories: Electric cutter, external rewinder (optional, customer must order at their own expense)

The Citizen CL-E730 industrial barcode printer is an upgraded and optimized version of the CL-S631, perfectly combining high performance, reliability, and innovative new features.

Citizen CL-E730 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 360-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ User-friendly control panel with a dual-color backlit LCD screen for clear machine status and easy settings.
◆ HI-OPEN allows all operations to be handled at the front of the printer, saving workspace.
◆ HI-LIFT opens the printhead to 90°, making consumable installation, cleaning, and maintenance very convenient.
◆ ARCP intelligent ribbon tension adjustment device ensures precise print positioning.
◆ Long-life printhead (over 30% more durable than similar products).
◆ Adjustable label sensor allows for quick setting of special labels.
◆ Automatic ribbon detection function can be activated to automatically detect low ribbon levels. The printer will detect the low ribbon level based on the ribbon diameter and automatically report an error via the LCD panel when the consumable is nearly depleted.
◆ Employs an ARM Cortax-A9 processor, significantly improving data processing speed.
◆ A brand-new communication interface, standard configuration includes two printer interfaces (LAN and USB), with optional serial port card, WIFI wireless network card, and IEEE1284 high-speed parallel port.
◆ Features a built-in power supply, eliminating the need for a bulky external power supply.
◆ CROSS-EMULATION automatically detects computer commands and provides language switching between Zebra and Datamax.

Citizen CL-E730 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 300 DPI (12 dots/mm)
Printing Speed: 1–6 inches/second (2.54–152 mm/s)
Print Width: 104 mm
Media Width: 25.4 mm–118 mm
Media Thickness: 0.0635 mm–0.254 mm
Maximum Outer Diameter of Media Roll: 200 mm
Minimum Inner Diameter of Paper Core: 25 mm
Media Sensor: Adjustable intensity, freely configurable position (between paper, black mark, bayonet, continuous)
Ribbon Size: 25.4 mm core, maximum outer diameter 74 mm, length 360 m
Ribbon Winding Method: External or internal carbon, automatic sensing
Ribbon Type: Wax-based, mixed, all-resin Ribbon System: ARCP automatic ribbon tension adjustment
Standard Interfaces: USB, Ethernet LAN
Optional Interfaces: Wireless LAN, Parallel Port, Serial Port
RAM: 32MB, 4.0MB user-available
Flash: 16MB, 4.0MB user-available
Control Panel: LCD display, color-changing backlight
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR code
English Fonts: 8 bitmap fonts, 1 Scalable font, supports TrueType font downloads
Chinese Fonts: None
Instruction Language: Datamax instruction set, Zebra ZPL II instruction
set Product specifications: 250 x 458 x 261 mm;
Product weight: 11 kg

The Citizen CL-E720 industrial barcode printer is an upgraded and optimized version of the CL-S621, perfectly combining high performance, reliability, and innovative new features.

Citizen CL-E720 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 360-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ User-friendly control panel with a dual-color backlit LCD screen for clear machine status and easy settings.
◆ HI-OPEN allows all operations to be handled at the front of the printer, saving workspace.
◆ HI-LIFT opens the printhead to 90°, making consumable installation, cleaning, and maintenance very convenient.
◆ ARCP intelligent ribbon tension adjustment device ensures precise print positioning.
◆ Long-life printhead (more than 30% more durable than similar products).
◆ Adjustable label sensor allows for quick setting of special labels.
◆ Automatic ribbon detection function can be activated to automatically detect when the ribbon level is low. The printer will detect the low ribbon level based on the ribbon diameter and automatically report an error through the LCD panel when the consumable is nearly depleted.
◆ Employs an ARM Cortax-A9 processor, significantly improving data processing speed.
◆ A brand-new communication interface, standard configuration includes two printer interfaces (LAN and USB), with optional serial port card, WIFI wireless network card, and IEEE1284 high-speed parallel port.
◆ Features a built-in power supply, eliminating the need for a bulky external power supply.
◆ CROSS-EMULATION automatically detects computer commands and provides language switching between Zebra and Datamax.

Citizen CL-E720 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 203 DPI (8 dots/mm)
Printing Speed: 1–8 inches/second (2.54–203 mm/s)
Print Width: 104 mm
Media Width: 25.4 mm–118 mm Media
Thickness: 0.0635 mm–0.254 mm
Media Length: 6.4 mm–812.8 mm
Maximum Outer Diameter of Media Roll: 200 mm
Minimum Inner Diameter of Paper Core: 25 mm
Media Sensor: Adjustable intensity, freely positionable (between paper, black mark, bayonet, continuous)
Ribbon Size: 25.4 mm core, maximum outer diameter 74 mm, length 360 m
Ribbon Winding Method: External or internal carbon, automatic sensing
Ribbon Type: Wax-based, mixed, all-resin Ribbon System: ARCP automatic ribbon tension adjustment
Standard Interfaces: USB, Ethernet LAN
Optional Interfaces: Wireless LAN, Parallel Port, Serial Port
RAM: 32MB, 4.0MB user-available
Flash: 16MB, 4.0MB user-available
Control Panel: LCD display, color-changing backlight
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR code
English Fonts: 8 bitmap fonts, 1 Scalable font, supports TrueType font downloads
Chinese Fonts: None
Instruction Language: Datamax instruction set, Zebra ZPL II instruction
set Product specifications: 250 x 458 x 261 mm;
Product weight: 11 kg

The Citizen CLP631 is a light industrial-grade barcode printer with a 306-dot resolution. It boasts powerful printing capabilities to meet a wide range of industry printing needs.

Using thermal transfer ribbon, it’s suitable for printing various labels on paper, PVC, PET, film, care labels, ribbons, and more. It delivers high-quality, stable, wrinkle-resistant, non-slip, and precise positioning.

The print head is durable and it’s primarily used by customers in manufacturing, logistics, apparel, government agencies, banks, and highways. Its user-friendly operation has earned it widespread praise from users.

Citizen CLP631 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 360-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, simpler and faster.
◆ Long-life printhead (over 30% more durable than comparable products)
. ◆ Adjustable label sensor allows for quick setting of special labels.
◆ Equipped with 8 MB of DRAM and 2 MB of flash memory, easily and quickly handling large print data tasks.
◆ Utilizes a powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with three standard printing interfaces (IEEE 1284 high-speed parallel port, serial port, and USB interface), and optional network card and WIFI interface.
◆ Built-in power supply eliminates the need for a bulky external power supply.
◆ Optional paper peeler and cutter modules are available to enhance the flexibility of printing applications.

Citizen CLP631 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 306 DPI (12 dots/mm)
Printing Speed: 1–4 inches/second (2.54–100 mm/s)
Print Width: 104 mm
Maximum Paper Width: 118 mm
Motherboard Memory: 8MB SDRAM, 2MB Flash ROM
Processor: 32-bit RISC High-Speed ​​Processor
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR Code
English font library: 8 bitmap fonts, 1 Scalable font, supports TrueType font download
Chinese font library: None
Instruction language: Datamax instruction set, Zebra ZPL II instruction set (optional)
Standard ports: IEEE 1284 parallel port, RS-232 serial port (25 pins), USB 1.10
Tag specifications: Width 19.5-118mm, Thickness 0.063-0.254mm, Length 6.4-812mm Roll or folding
Paper specifications: Label paper roll, outer diameter 127mm (5″), paper core inner diameter 25.4～76mm (1～3″)
Product specifications: 231 x 289 x 279 mm, (9.1″ x 11.4″ x 10.6″)
Product weight: 4.5kg, (9.9) Optional accessories (Lbs)
: electric cutter, label peeler, external high-capacity paper holder (200 meters), external rewinder (optional, to be ordered by the customer at their own expense).

The Citizen CLP621 is a light industrial-grade barcode printer with a 203-dot resolution. It offers excellent value for money, offering the same functionality as the CLP-631.

With powerful printing capabilities, it can meet the printing needs of a wide range of industries. Using thermal transfer ribbon, it is suitable for printing various labels on paper, PVC, PET, film, care labels, ribbons, and more. It boasts high-quality, stable, wrinkle-resistant, non-slip, precise positioning, and a durable printhead.

Primarily used by customers in manufacturing, logistics, apparel, government agencies, banks, and highways, its user-friendly operation has earned it widespread praise from users.

Citizen CLP621 Features:
◆ All-metal printhead design ensures durability and reliable operation.
◆ Supports up to 360-meter ribbons, reducing ribbon changes and improving printing efficiency.
◆ CITIZEN’s unique open print module structure and visual color coding design make ribbon and label installation, as well as printer cleaning and maintenance, simpler and faster.
◆ Adjustable label sensor allows for quick setting of special labels.
◆ Equipped with 8 MB of DRAM and 2 MB of flash memory, easily and quickly handles large print jobs.
◆ Utilizes a powerful 32-bit RISC processor for high-efficiency data transmission and processing.
◆ New communication interface with three standard printing interfaces (IEEE 1284 high-speed parallel port, serial port, and USB interface), and optional network card and WIFI interface.
◆ Built-in power supply eliminates the need for a bulky external power supply.
◆ Optional paper peeler and cutter modules enhance printing application flexibility.

Citizen CLP621 Detailed Specifications:
Printing Method: Thermal Transfer/Direct Heating
Printing Resolution: 200 DPI (8 dots/mm)
Printing Speed: 1–4 inches/second (2.54–100 mm/s)
Print Width: 104 mm
Maximum Paper Width: 118 mm
Motherboard Memory: 8MB SDRAM, 2MB Flash ROM
Processor: 32-bit RISC High-Speed ​​Processor
1D Barcodes: Code3of9, UPC-A, UPC-E, Interleaved2of5, Code128, EAN-13, EAN-8, HIBC, CODABAR(NW-7), Plessey, Int2 of 5, CASE CODE, Code93, ZIP, UPC2DIG ADD, UPC5DIG ADD, UCC/EAN128 (for K-MART), RandomWeight, Telepen, FIM, UPS
2D Barcodes: MaxiCode, PDF417, Data Matrix, and QR Code
English font library: 8 bitmap fonts, 1 Scalable font, supports TrueType font download
Chinese font library: Built-in Chinese font library
Instruction language: Datamax instruction set, Zebra ZPL II instruction set (optional)
Standard ports: IEEE 1284 parallel port, RS-232 serial port (25 pins), USB 1.10
Tag specifications: Width 19.5-118mm, Thickness 0.063-0.254mm, Length 6.4-812mm Roll or folding type
Paper specifications: Label paper roll, outer diameter 127mm (5″), paper core inner diameter 25.4～76mm (1～3″) Product specifications: 231 x 289 x 279 mm, (9.1″ x 11.4″ x 10.6″) Product weight: 4.5kg, (9.9
” x 11.4″ x 10.6″) Optional accessories
(Lbs)
: electric cutter, label peeler, external high-capacity paper holder (200 meters), external rewinder (optional, to be ordered by the customer at their own expense).
